Aktiv 12″ kraftig flerbruksmonitor som kan brukes som topp, monitor eller fill høyttaler. Brukervennlig mikserpanel m/ kraftig DSP med justerbare parametre. Mikrofon, linje og phono innganger.

Technical specifications
Description	Powered monitor speaker for multifunctional applications
Maximum amplifier output capability	520 W
Low amplifier power	360 W IHF-A, 260 W RMS
Mid-high amplifier power	160 W iHF-A, 75 W RMS
Maximum SPL (1 meter)	128 dB (calc.)
Frequency range (-10 dB)	50–20000 Hz
Coverage angle nominal	90° horizontal x 90° vertical
Crossover frequency	1.6 kHz
Transducer	DCX 12300, 12-inch/1.75-inch 2-way coaxial transducer
	with lightweight neodymium compression driver
Audio sockets
Inputs	2 x Mono XLR/Jack socket (MIC/LINE)
	Switchable phantom power
	1 x Stereo RCA (AUX IN)
Outputs	1 x XLR THRU (parallel to MIC/LINE 1)
	1 x XLR MIX OUT
Equalization	Low shelving filter ±10 dB / 60 Hz
	Mid peak filter ±10 dB / 70–12000 Hz
	High shelving filter ±10 dB / 12 kHz
Filter	Low-cut filter f = 50–200 Hz, 12 dB/oct.
	Feedback filter 70–10000 Hz, Notch, -10 dB
Master delay	0–100 m
Settings	5 factory presets, 5 user settings
Display	Blue backlit LC-display, dimmable
AC power input	100–240 V AC, 50–60 Hz
AC power consumption	0.8–0.5 A
Cooling Passive
Safety class I
Operating temperature	0 °C to 40 °C
Product dimensions (W x H x D)	414 x 339 x 484 mm
Net weight	14.9 kg
Shipping weight	18.4 kg
Enclosure material	15 mm birch plywood
Enclosure finish	Heavy duty structured lacquer
Color Black	(RAL 9005, jet black)
Grille	Powder coated steel, acoustic foam
Pole mount adaptor	1
Handles	1 x bar carry handle, 2 x recessed grip
